Standard Features:

​

1. Advanced HMI (Human Machine Interface) system, with data storage and malfunction alarm function, easy to use.
2. Twin servo driven positioning system, high precision filling control, HMI system setting filling.
3. Anti-foaming design, with double anti-dripping device
4. 304 stainless steel for appearance structure and SUS316 stainless steel for liquid contacted material, fully compliance to food hygienic standard.
5. Very convenient to clean, without any remaining.
6. PLC combined with touch screen control system.
7. CE conformity.

​

​

Option:

​

1. Infeed and outfeed turn table
2. Safety transparent cover for safe operation circumstance and dust-proof.
3. Special Bottle shape moulds or bottle feeding auger

Model   AFLS-120            AFLS-500            AFLS-1000          AFLS-2500     AFLS-5000

Filling Range (ml)            10-120 50-500 100-1000            250-2500     500-5000

Filling Nozzles    8            8            8            8            8

Filling Speed (BPM)         30-60    30-60    30-50    30-50    30-40

Tolerance           ≤ ±1- 2%             ≤ ±1- 2%             ≤ ±1- 2%               ≤ ±1- 2%             ≤ ±1- 2%

Working Voltage              380V, 50/60 Hz 380V, 50/60 Hz 380V, 50/60 Hz            380V, 50/60 Hz 380V, 50/60 Hz

Max Power         3.5 kW 3.5 kW 3.5 kW 3.5 kW 3.5 kW

Working air pressure      0.4-0.6(Mpa)     0.4-0.6(Mpa)     0.4-0.6(Mpa)            0.4-0.6(Mpa)     0.4-0.6(Mpa)
