Feature Model Specification

• Assumed usage (hours/year):      3,000 to 8,500
• Lines of print:          1 - 5 lines
• Character height:             1.5mm to 12mm
• Font height:           5 to 31 dots
• Line speed at 5 drop and 50 dp:    i up to 10.6 m/s
• Nozzle size:         50μm
• Drop size:            50μm
• PixelPlus:             No
• ciLink:                  Yes
• Inputs (photocell / shaft encoder / programmable):          2 / 1 / 8
• Cabinet Material:             Stainless Steel
• IP Rating:             ci5500 (IP55), ci5650 (IP65)
• Weight (including printhead):      ci5500 (18kg), ci5650 (18.7kg)

Feature ci5000 Series Specification

• 10.1" Touch Screen:         Yes
• ciEasyServ:                      Yes
• ciPrecisionPlus:                Yes
• SmartFlush:                      Yes
• ciSafeFill:                          Yes
• Programmable Alarms / Relays:   3 / 1
• Conduit Length:                9ft (2.75m) as standard
• Service Interval:                Service intervals of 8,000 hours or 18 months, depending on environment
• Languages:          English, Spanish, French, German, Italian, Chinese (Simplified), Chinese (Traditional), Russian, Bulgarian, Kasakh, Macedonian, Arabic, Vietnamese, Korean, Japanese, Polish, Latvian, Lithuanian, Estonian, Turkish, Thai, Hebrew, Greek, Danish, Swedish, Norwegian, Finnish, Portuguese, Brazilian, Romanian, Croatian, Slovenian, Serbian, Albanian, Slovak, Czech, Hungarian, Dutch, Hindi, Urdu, Persian and Swahili.
• Power:             90 - 240V:(3 Amp), auto-ranging; 50 - 60Hz
• Operating Temperature Range:    5ºC to 45ºC, ink dependent
• Operating Humidity Range:          10% to 90%, non-condensing
• Tank Sizes:                      1.9 liter ink tank; 2.25 liter make up tank

HS50 High Speed Compatible Inks

• General Purpose MEK Black
• General Purpose MEK Red
• General Purpose MEK Blue
• General Purpose Ethanol Black
